GVSNEW 2026KNX DIMMING ACTUATORS
1-10V Dimming Actuator with Secure,3-Fold,16A,Flush Mounted
PRICE — PARTNERS
Auriga publishes pricing to approved partners only. Dealers buy at 30% off list, KNX-certified partners at 35%, and any single order over $50,000 at 40%.
SPECIFICATIONS
| GVS model | ADTVF-03/08.1 |
|---|---|
| Article no. | 101210044 |
| Dimensions | 1.97×2.36×0.81 in (50.0×60.0×20.5 mm) |
| Protocol | KNX / KNX Secure |
| Category | KNX Dimming Actuators |
| Distribution | Auriga Systems LLC — exclusive GVS distributor, US & Canada |
MANUFACTURER DESCRIPTION
- Passive DC 1-10V drive mode, One channel max. 16A.Switch current 16A /250V AC, no
- additional voltage input.KNX functions including swicth, relative & absolute dimming(support
- normal dimming output, RGB output, CCT output), status response, scene control (16 folds),
- preset, staircase lighting etc.Can be individually configured per 4-fold input & 4-fold input/LED
- output, cable length≤10M, dry contact input, 12V DC LED output.
- Power: KNX Bus only; Consumption: bus 12mA
- Installation: DIN-rail Mounted
